Insertion Type Sim Card Socket Connector 6 Pin Height 2.9mm Card Connector

Sim Card Socket Connector insertion type 6p height 2.9mm card connector

This series are SDMC (Secure Digital Memory Card) Connectors used as the recording medium of portable devices, which can be widely introduced into the market of notebook PCs, mobile phones, DVCs (Digital Video Cameras), DSCs (Digital Still Cameras) and other complex machines for these applications.

Product informations
Name	SIM card connector
Brand name	XTK
Type	SIM series
Product specifications
Operating temperature	-20 ℃ TO +60 ℃
Life	500,000 times
Rated current	1.5A
Rated voltage	30V
Durability	3000 Cycles MIN
Resistance voltage	500V AC MIN.
Contact impedance	30mΩ MAX. Initial; 40 m Ω MAX
Insulation resistance	1000mΩ MIN
Product material
Rubber core	PBT/LCP UL94V-0
Terminal	Brass C2680/Nickel base/Gold plated 1 U
Shell	SPCC/C2680 all-area nickel plated 40 U MIN

Insertion Type Sim Card Socket Connector 6 Pin Height 2.9mm Card Connector

1. XTKCONN House has many types card connectors: CF/SD/TF/SIM/XD/MICRO SD card connector.

2. All parts and accessories are made of environmentally friendly materials, in line with the latest RoHS,REACH requirements.

3. The solder joint fitting flatness is controlled at 0.1mm, and the contact tolerance is controlled at 0.02mm.
